Naviate Rebar Extension

Automated reinforcement for your structures

Perform an automated process to generate reinforcement for elements such as beams, columns and piles.

Beams: generate reinforcement for a rectangular cross-section of a beam in a Revit and Robot.
Columns: generate reinforcement for rectangular and round cross-sections of an RC column in a Revit and Robot.
Piles: generate reinforcement for a single pile or a group of piles in a Revit model.

Here's how it works:

Select the elements of the structure where you want to generate the reinforcement.
Enter the parameters that you want to use.
Once the Naviate Rebar Extension has generated the reinforcement, you will be updated on the process to generate the reinforcement within individual, specific elements.

Note: you can generate the reinforcement for all elements except retaining walls and plate corners.
